48V 100Ah LiFePO4 Aerial Lift Platform Deep Cycle battery, specification for upgarding Aerial Lift Platform with Lead-Acid battery, Lithium-ion battery pack for Aerial Lift Platform manufacturer
· Aerial Lift Platform battery
· 48 volt lithium-ion battery
· Longer Lifespan
· More Productivity
· Fast Charging
· No Maintenance/No Watering
· Commercial Grade Steel Case
· RS485/CAN communication
· Customize Specification or Logo Acceptable
AERIAL LIFT PLATFORM BATTERY SPECIFICATIONS
· Nominal capacity: 100Ah
· Open circuit voltage: 51.2V
· Self-discharge: <3% per month
· Cycle life: >3000 (at 10C discharge, 100% DoD)
· EqPb (Equals Lead acid battery): 480Ah
· Voltage: 48V
· Dimensions (LxWxH): Customization
· Weight: Customization
· Case material: Commercial Grade Steel
· Ingress protection: IP65
· Cell type / Chemistry: Lithium – LiFePO4
· Group mode: 16S2P
CHARGE & DISCHARGE SPECIFICATIONS
· Charge method: CCCV
· Charge connector: REMA160（fix on the battery box ）
· Discharge connector: REMA320（cable length 1 meter）
· Charger: Input voltage 220V single phase, output 70A
· Maximum continuous charging current: 400A
· Max instantaneous charging current(10S): 200A
· Max instantaneous discharging current(10S): 600A
· Recommendation standard charging current: ＜100A
· Working Voltage Range: 44.8V~57.6V
· Charge temperature: 0°C to 50°C / 32°F to 131°F
· Discharge temperature: –20°C to 55°C / -4°F to 131°F
· Storage temperature: 0°C to 40°C / -4°F to 113°F
· Certifications: CE, UN 38.3, UL,IEC, CB, ISO9001
· Shipping classification: UN 3480
· Vehicle communication mode: CAN
· Display communication method: RS485
JB BATTERY, as one of the top forklift battery factory manufacturers, material handling machine battery provider. We have developed lithium iron phosphate (LiFePO4) batteries. We offer high performance lithium-ion batteries for electric forklift, Aerial Lift Platform(ALP), Automated Guided Vehicles (AGV), Autonomous Mobile Robots (AMR) and Autoguide Mobile Robots(AGM).
As professional forklift battery suppliers, we provide customers with lithium forklift battery solutions. JB BATTERY LiFePO4 batteries have the characteristics of high energy density, long cycle life, high safety performance, product consistency, and can adapt to a wide range of environments.
Our forklift battery adopts an intelligent management system that can fully control the system, achieve automatic battery output balance and extend the battery life. Intelligent thermal management circuit design fully safeguards reliable operation at high and low temperatures. With the features of maintenance-free, zero-emission, long life, strong power, the batteries ensure the equipment to work stably in the long term.
With the development of the Internet economy, the freight industry is developing rapidly. In addition to global green growth, energy conservation and emission reduction are significant forces in the future. It’s time to upgrade our gas forklift and lead-acid battery forklift. We understand that the total cost and reliability of the forklift are the two most important factors. JB BATTERY lithium-ion forklift battery manufacturer has rich experience in lifepo4 forklift battery design and production. We can meet all kinds of customer requirements, such as battery status monitoring, communication, battery counterweight, to complete the seamless replacement of old batteries or direct electrification upgrade. We can solve the above two concerns and other specific demands of our customers at the same time.
If you want to upgrade your Lead-Acid power forklifts, or you’re a forklift manufacturer, as a reliable supplier, please contact us, we will offer the best lithium-ion batteries for your forklifts. We will be able to bring lasting support to your career development.
As a lithium battery specialist, JB BATTERY has a comprehensive product portfolio, including:
12 volt lithium-ion battery,
24 volt lithium-ion battery,
36 volt lithium-ion battery,
48 volt lithium-ion battery,
60 volt lithium-ion battery,
72 volt lithium-ion battery,
80 volt lithium-ion battery,
96 volt lithium-ion battery,
120 volt lithium-ion battery,
for forklift trucks, ALP, AGV, AMR, AGM power supply.
At JB BATTERY, we offer customized foklift battery services for your foklifts. You can customize the voltage, capacity, case material, case size, case shape, charge method, case color, display, battery cell type, waterproof protection.
